800mm
1.1m
1500kg
| I T E M | TG800 | UNIT | |
Working range | Clamping surface | ∅800 | mm |
| C-axis rotary-diameter at A-axis center | ∅1100 | mm | |
| Distance A-axis-center to rotary-table | 100 | mm | |
| A-axis swivel diameter(swing)at X-axis center | 790 | mm | |
| Table Load max. | 1500 | kg | |
| 进给轴 Feed-drive system | X/Y/Zaxis traverse path | 800/1000/600 | mm |
| Swivel range of A-axis | ±140 | o | |
| Swivel range ofC-axis | N*360 | o | |
| Distance spindle-table min./max. | 190-790 | mm | |
| Max.rapid travelX/Y/Zaxis | 60 | m/min | |
| A/Caxis rate speed | 30/60 | rpm | |
| A/Caxis max.torque | 7000/14000 | Nm | |
| A/Caxis rate speed | 50/100 | rpm | |
| A/Caxis max.torque | 1500/3000 | Nm | |
Motor-spindle drive | Cutting-toolinterface | HSK-A63 | |
| Motor-spindle max.speed | 16000 | rpm | |
| Motor-spindle torque SI/S6-25% | 177/292 | Nm | |
Tool magazine | Tool positions | 48 | T |
| Max.toldiameter/length | ∅75/350 | mm | |
| Max.tool diameter/length | ∅125/350 | mm | |
| Max.tool weight | 8 | kg | |
| Accuracy | X/Y/Zaxispositioning accuracy ISO10791-4:1998 | 0.006 | mm |
| A/Caxis positioning accuracy ISO 10791-4:1998 | 7 | ARCSEC | |
| X/Y/Zaxis repeat positioning accuracy ISO 10791-4:1998 | 0.004 | mm | |
| A/Caxis repeat positioningaccuracy ISO10791-4:1998 | 4 | ARCSEC | |
| Dimensions length/width /height(front) | 2560/4430/4150 | mm | |
| Machine weight(Not include accessories) | 17000 | kg | |
| Power consumption | 80 | KVA | |
* Parameter updated in May 2026 version
